In previous articles in the Beaglebone 101 series, I covered digital GPIO, analog and serial pins, PWM and SPI.

One important coding interface remains: I2C.  I’ll cover it today, including I2C input and output, and level conversion, culminating in the Weatherbone, a basic LCD-based thermometer.

I2C Overview

I2C’s main advantage is simplicity.  It requires just 4 connections, 2 fewer than SPI: voltage, ground, clock and data.

The clock pin works pretty much the same way as with SPI: it is driven by the Beaglebone to control the timing of the data transfer, and works fine at 3.3V even when interfacing to a 5V device.  As with SPI, one option for controlling the state of the I2 clock pin is “bit banging”: using a plain old GPIO pin as the clock.  However, since the Beaglebone supports much higher and more reliable clock speeds through specialized hardware, we’ll make use of that.

Unlike SPI, I2C uses just 1 data pin, which transfers data in both directions.  This is great for simplicity and cost, not so great for speed.  As a result, I2C devices is most appropriate for devices that don’t send a lot of data, like sensors.

The fact that data travels in both directions on the same pin is an important consideration when interfacing with a 5V device: you must always use a level shifter on the data pin.  This is necessary even if using an output device like an LCD — there is no such thing as a “write only” connection when dealing with I2C.  I’ll give an example of level shifting in the I2C LCD circuit.

Like SPI, I2C supports multiple devices on the same I2C bus.  While SPI uses a latch pin to select the device, I2C handles the addressing with software.  This, again, makes wiring the circuit easier.

I2C and the Beaglebone

Most Beaglebone distros allow access to 2 I2C buses: /dev/i2c-1 and /dev/i2c-3.  For reasons that I don’t fully understand, /dev/i2c-1 doesn’t play nice with user applications, so we’ll stick with /dev/i2c-3.

The 2 pins used to interface with I2C bus 3 are pins 19 (clock) and 20 (data) on port 9.  Both pins default to I2C mode in Ubuntu and Angstrom, so no pinmuxing is required.

You may have seen references to the importance of pull-up resistors when using I2C.  You can ignore this when using the Beaglebone, since pull-up resistors are enabled by default on pins 19 and 20 in both Ubuntu and Angstrom.

When accessing SPI devices from Python, I used a C language extension (spimodule.c) as a go-between.  With I2C this isn’t necessary, since a Python-friendly interface exists: SMBus.   Technically, SMBus and I2C aren’t the same thing, but they both support the high-level read and write actions used by most applications.

Installing SMBus on Ubuntu is easy:

sudo apt-get install python-smbus

Updated 12/20/12 – I finally had a chance to try installing smbus on Angstrom.  It wasn’t as straightforward as the original text of this article suggested: here are the gory details..

Installing SMBus on Angstrom is somewhat more difficult.   There is no Angstrom package for python-smbus, so you’ll need to download it from source:

1/6/13: Added some corrections to the following instructions, as provided by the Hipstercircuit blog.  See Hipster’s instructions on getting an I2C PWM controller to work on Beaglebone Angstrom,  a good way of extending the Bone’s relatively limited PWM capabilities.

opkg install kernel-headers python-distutils
wget http://dl.lm-sensors.org/i2c-tools/releases/i2c-tools-3.1.0.tar.bz2
tar -xjf i2c-tools-3.1.0.tar.bz2
cd i2c-tools-3.1.0/py-smbus

Edit setup.py to add a new “include_dirs” line, as  highlighted in bold below:

...

 url="http://lm-sensors.org/",
 include_dirs=["../include", "/usr/include"],
 ext_modules=[Extension("smbus", ["smbusmodule.c"])])

Without that change, python setuptools won’t be able to find the “limits.h” file.

Run the standard python build command:

python setup.py install

You’ll get a new error “this linker was not configured to use sysroots”.  I don’t know how to properly fix this error, but a workaround is to run the same command without the sysroots parameter. The error message will include the full command, so just copy it to the clipboard and remove the part that begins with “–sysroot”.  On my PC, the resulting command was:

arm-angstrom-linux-gnueabi-gcc -march=armv7-a -fno-tree-vectorize
 -mthumb-interwork -mfloat-abi=softfp -mfpu=neon -mtune=cortex-a8
 -D__SOFTFP__  -shared -Wl,-O1 -Wl,--hash-style=gnu
-Wl,--as-needed
-I../include build/temp.linux-armv7l-2.7/smbusmodule.o
-L/usr/lib -lpython2.7 -o build/lib.linux-armv7l-2.7/smbus.so

Lastly, run the python build command again to finish the process:

python setup.py install

The MCP23008 Port Expander

The MCP23008 is the I2C equivalent of the 74HC595 chip that I covered in my SPI article.  As mentioned then, port expanders aren’t terribly useful with the GPIO-rich Beaglebone, but when combined with buttons and LEDs the MCP23008 provides a quick and easy way of testing I2C circuits and code.

Compared to the Beaglebone’s GPIO pins, the MCP23008 does offer a few advantages:

1. It can interface directly with 5V devices.  Note that this requires powering the MCP23008 with 5V, so you still need to use a level shifter to connect the MCP23008′s data pin to the Beaglebone’s data pin.  But converting one pin is, of course, a lot easier than converting each GPIO pin separately.

2. It can source and sink a higher amount of current than the Beaglebone: 20 ma, compared to just 6 ma source and 8 ma sink for the Beaglebone.

3. It has registers to support interrupts.  This means that code doesn’t have to rely on polling to detect input — sort of.  I’ll show an example of that below.

To demonstrate the input and output interface to the MCP23008, I’ll use the circuit shown below:

On the Beaglebone, pin 19 on Port 9 is I2C Clock, and pin 20 is data.  Since I’m powering the MCP23008 at 3.3V, these can be directly connected to the chip’s pins 1 and 2.

The 3 address pins of the MCP23008 are all connected to ground.  These pins determine the address that is specified in our code to select the MCP23008, and are important when using multiple MCP23008s: since there is no latch pin, the address determines which chip gets the data.  With all 3 address pins connected to ground, we’ll use the MCP23008′s base address of 0×20.

Pins 10 (GP0) and 16 (GP6) are used as input pins, connected to a pushbutton that is connected to ground.  The MCP23008 has an optional pullup resistor, which we’ll enable on this pins.  So, the pin is normally high, but when the button is pressed it will change to low.

Pins 11 (GP1) and 17 (GP7) are connected to LEDs through resistors (anything in the range of 330 to 680 is fine).

The idea is that the buttons will toggle the state of the LEDs.  Yes, that does sound suspiciously like the same thing that we were doing back in the first Beaglebone Coding 101 article, but 2 LEDs makes it twice as exciting!

Before running the code, it’s a good idea to run the i2cdetect command to make sure that your MCP23008 is correctly connected.  This is part of the i2c-tools package, which is preinstalled in Beaglebone Ubuntu.  (If it’s not in your copy, run “sudo apt-get install i2c-tools.)

The MCP23008 should be detected at address x20, as shown below:

ubuntu@omap:~ sudo i2cdetect -r -y 3
 0 1 2 3 4 5 6 7 8 9 a b c d e f
00: -- -- -- -- -- -- -- -- -- -- -- -- --
10: -- -- -- -- -- -- -- -- -- -- -- UU -- -- -- --
20: 20 -- -- -- -- -- -- -- -- -- -- -- -- -- -- --
30: -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- --
40: -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- --
50: -- -- -- -- UU UU UU UU -- -- -- -- -- -- -- --
60: -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- --
70: -- -- -- -- -- -- -- --

The Python code for this article can be downloaded from my Google Code page by running the following commands on your Beaglebone:

wget http://gigamega-micro.googlecode.com/files/WeatherBone.tgz
tar -xzvf WeatherBone.tgz
cd WeatherBone

The code for this circuit makes use of 2 Python classes:

• Adafruit_I2C  - This is part of Adafruit’s Python library for the Raspberry Pi.  The code was almost 100% compatible with the Beaglebone: I only had to modify the bus number passed to SMBus (0 for the Pi, 3 for the Beaglebone)
• gm_mcp23008.py – This is a wrapper I wrote for the MCP23008.

gm-mcp23008.py has a short bit of test code at the bottom, which is executed if you run it directly from python.

sudo python gm-mcp23008.py

You should find that the buttons faithfully toggle the LEDs’ state, with a slight pause.

The code begins with

mcp = mcp23008(3, 0x20, True)

The 3 parms being passed are the I2C bus number (3), the MCP23008 address (0×20), and a Debug flag that results in a message being written to the console each time I2C data is sent or received.

The code then initializes the 4 pins a la Arduino:

# button 1 connected to ground on pin 0 of MCP23008
mcp.pinMode(0, mcp.INPUT, True, mcp.INTERRUPT_PREVVAL, mcp.EDGE_LOW)
# LED 1 on pin 1
mcp.pinMode(1, mcp.OUTPUT)
# button 2 connected to ground on pin 6 of MCP23008
mcp.pinMode(6, mcp.INPUT, True, mcp.INTERRUPT_PREVVAL, mcp.EDGE_LOW)
# LED 2 on pin 7
mcp.pinMode(7, mcp.OUTPUT)

The INTERRUPT_PREVVAL and EDGE_LOW parameters require some explanation.

The MCP23008 supports interrupts, internally using some registers, and externally through pin 8 (which I’m not using).  The registers can be used to detect a case where the user pressed and released the button when the Python code wasn’t checking the pin.

The INTERRUPT_PREVVAL setting will trigger an interrupt when the pin state changes, and the EDGE_LOW parm will limit that to when it changes from high to low (remember, the pin goes from high to low when the button is pressed).

A good resource for learning more about the MCP23008′s registers is this article on embedded-lab.com.

The main part of the Python code loops indefinitely, checking the state of the buttons once per second — a leisurely rate that I’m using to test the interrupts:

# toggle LED when button is pressed
while 1 == 1:
   # NOTE!! - must get interrupts before reading pins, since reading pins clears the interrupts
   interrupt1 = mcp.wasInterrupt(0)
   interrupt2 = mcp.wasInterrupt(6)
   if interrupt1 or mcp.digitalRead(0) == mcp.LOW:
      led1State = not led1State
      mcp.digitalWrite(1, led1State)

   if interrupt2 or mcp.digitalRead(6) == mcp.LOW:
      led2State = not led2State
      mcp.digitalWrite(7, led2State)

   time.sleep(1)

As indicated by the comment, reading a pin’s state clears any interrupt for it. So, it’s necessary to call the wasInterrupt() method for both pins first.  This method returns True if the button was pressed since the last time the code checked (i.e. since the last call to digitalRead).

Writing to an LCD using the Adafruit I2C Backpack

As in my SPI article, I’ll leverage the GPIO extender code to write to a standard character LCD, using the Adafruit I2C/SPI LCD Backpack.

The backpack runs on 5V, and that voltage kills Beaglebones.  This wasn’t a concern when using SPI.  SPI uses a separate pin for input and output, so we were able to drive the output pin at 3.3V and leave the input pin disconnected.

With I2C, we need to use a level converter between the backpack and the Beaglebone’s I2C pins.  I used a $2 converter from Sparkfun.  I used the same Sparkfun board as a voltage divider in my article about analog input: the TX pins are level converters, while the RX pins are voltage dividers.  In this case, we want to use the TX pins.

I also made a small modification to the backpack to enable setting the backlight brightness via PWM.

The backpack normally feeds 5V into pin 15 of the LCD (the second from the end), resulting in maximum brightness.  As shown in the photo below, I’ve left pin 15 unsoldered in the backpack, connecting it instead to a NPN transistor.  One of the Beaglebone’s PWM pins is  connected to the base of the transistor.   A potentiometer attached to an analog pin is used to control the duty cycle setting of the PWM pin.

The PWM pin outputs 3.3V, which results in a noticeably dimmer LCD backlight, even though the transistor’s collector pin is connected to 5V.  So, I made use of the level converter to shift the PWM signal from 3.3V to 5V.

If all that seems way too complicated, you could actually avoid the need for level conversion by using the transistor with the LCD’s pin 16 instead of 15, connecting it to ground instead of 5V.  The only downside to that approach is you lose the API support for turning the backlight off and on, but the potentiometer can be used for this instead.

The circuit is shown below.  (The BMP085 part is explained in the next section.)

The Beaglebone pins are all on Port 9.  Along with ground, 3.3V and 5V, the pins are:

• Pin 14 – PWM – white wire
• Pin 19 – I2C Clock – brown wire (with no level conversion required)
• Pin 20 – I2C Data – yellow wire (with level conversion)
• Pin 32 – Analog 1.8V – orange wire
• Pin 41 – Analog In – green wire

The Adafruit I2C backpack is (kind of) shown in the upper right of the diagram.  The wires leading to it are connected to:

• Data – yellow wire1
• Clock – brown wire
• 5V – red wire
• Ground – blue wire
• Pin 15 of the LCD – Orange wire

I wrote a Python class, i2clcd to provide Arduino-like methods for writing to the LCD through the I2C port.  It’s included in the download file.

As a quick test, you can just run the Python class directly, which should turn on the backlight and write some text to the LCD:

sudo python i2clcd.py

The i2clcd class supports many of the same methods as the Arduino LiquidCrystal library.  So, to write text to all 4 lines of a 4×20 LCD:

# the LCD is connected to I2C bus 3

l = i2clcd(3)

l.begin(20, 4)
l.noBlink()
l.noCursor()
l.setBacklight(True)

l.clear()

for row in range(4):
   l.setCursor(0, row)
   l.Print("This is row " + str(row + 1))

Connecting Multiple I2C Devices

It’s quite easy to connect multiple devices to the same bus: just connect their clock pins and their data pins.  This is a lot simpler than controlling multiple SPI devices, which require a separate latch pin for each device.

I added a BMP085 to the circuit to demonstrate this.  It is powered by 3.3V, but coexists fine with the 5V LCD backpack provided that its data pin is connected to the 3.3V side of the level converter.

The code to read the BMP085 is taken from Adafruit’s Raspberry Pi Python library – it works on the Beaglebone without any changes at all.

To give all of the hardware something to do, I wrote a Python program, WeatherBone.py, to read the temperature and barometric pressure from the BMP085, and display that along with the sunrise and sunset time to the LCD.

Wrapping Up

The interfaces that I’ve covered in the Beaglebone Coding 101 series can be used to connect your Beaglebone to almost any type of device in the microcontroller world.

I have to admit that I’m not sure how big a gap the “almost” part leaves, since I tend to go down the path of least resistance.  If a particular sensor seems to be a little beyond the Beaglebone’s grasp (or beyond my grasp as a coder, anyway), I’ll switch to an equivalent sensor that uses a standard interface, or which others have already written code for.

The good news is that the paths of least resistance in embedded Linux coding are increasingly well marked, thanks to the Raspberry Pi.   It’s great to see so many new articles and sample code coming out of the Pi community.  The Pi’s code is generally easy to port to the Beaglebone, and the increased interest in embedded Linux is boosting both platforms.

Update Dec 16 2012 – As pointed out in the comments, the PWM clock is activated by default in the current Angstrom version, Revision A6A.  If you are running this image, there is no need to use mmap to activate thte clock.

My earlier articles [1, 2] on Beaglebone coding ignored one of the basics: digital input.  The main reason I skipped it is that the I only knew how to handle input by polling, and polling is lame.  I decided to wait until I had some Python code to handle input using interrupts, and write about that instead.

Well, here we are, a couple of months later, and … um … it turns out that polling is cool.  Interrupts are lame.  You know who uses interrupts?  Microsoft!  Need I say more?

I’ll also cover a relatively new addition to the Beaglebone’s kernel, PWM.

Digital Input

The Beaglebone has a number of pins that default to GPIO mode, and all of them are initially configured for input, not output: the receive feature is enabled, and the GPIO direction flag is set to “in”.

If you take a look at the pin mux settings for these pins, you’ll notice they are similar, but not the same.

For example, here is Port 8 Pin 3:

root:/sys/kernel/debug/omap_mux# cat gpmc_ad6
 name: gpmc_ad6.gpio1_6 (0x44e10818/0x818 = 0x0037), b NA, t NA
 mode: OMAP_PIN_OUTPUT | OMAP_MUX_MODE7
 signals: gpmc_ad6 | mmc1_dat6 | NA | NA | NA | NA | NA | gpio1_6

And here is Port 8 Pin 11:

root:/sys/kernel/debug/omap_mux# cat gpmc_ad13
 name: gpmc_ad13.gpio1_13 (0x44e10834/0x834 = 0x0027), b NA, t NA
 mode: OMAP_PIN_OUTPUT | OMAP_MUX_MODE7
 signals: gpmc_ad13 | lcd_data21 | mmc1_dat5 | mmc2_dat1 |
 NA | NA | NA | gpio1_13

Both pins are configured for Mode 7 (GPIO mode), but Pin 3′s mux setting is x37, and Pin 11′s is x27.

From the mux register description in the AM335x Technical Reference, we know that this means both pins are configured for input (Received enabled), but Pin 3 is set to use pullup resistors, and Pin 11 is set to use pulldown resistors.

By default, then, Pin 3 reads HIGH when nothing is connected to it, and Pin 11 reads LOW.

Sure enough, if we export the pin, then look at its value, we see that it is a 1 for Pin 3:

root:/sys/class/gpio# echo 38 > export
root:/sys/class/gpio# cd gpio38/
root:/sys/class/gpio/gpio38# cat value
 1

…and a zero for Pin 11:

root:/sys/class/gpio# echo 45 > export
 root:/sys/class/gpio# cd gpio45
 root:/sys/class/gpio/gpio45# cat value
 0

I have no idea why these default settings were chosen: possibly to give creators of capes more plug-and-play flexibility, possibly to give me yet another opportunity to write about mux settings, or maybe they just couldn’t decide.  However, when you hook up a circuit you really do have to make a choice.

With Pin 3′s setting, a button (or any other digital input device), needs to connect to Ground when the button is pressed.  If you connect it to a voltage pin, nothing good will come of it, but quite possibly a lot of bad.

The GPIO pins on the Beaglebone are quite fragile, compared to the Arduino‘s or Netduino‘s.   The Arduino is happy with 5V of input, but can also work with 3.3V.  The Netduino prefers 3.3V, but is 5V “tolerant”, meaning you can get away with it.  The Beaglebone, on the other hand, is decidedly intolerant of 5V.  Hook it up to 5V, even for a split second, and it will die.  I wish I could say that I learned this by reading about it, but you can trust me on this one.

The GPIO pins are also more delicate than the Arduino when it comes to current.

According to this post  by Beaglebone hardware designer Gerald Coley, the recommended max output current through a pin is 4-6 mA, and the max input current is 8 mA.  On the Arduino, it is 40 mA.  (Based on my own experience, the Beaglebone seems to be tolerant of higher currents: I’ve measured 60 mA coming out of a GPIO pin.  That was a different Beaglebone than the one that died, by the way. What can I say: I’m the Michael Vick of electronics!)

For this reason, I think it’s safest to configure a digital input pin with a pull-up resistor, and connect the button to ground.  If you go the other way and use a pull-down resistor, be very certain you don’t accidentally hook it up to the 5V pins, and be sure to use an external resistor too – the internal pull-down resistor won’t knock down the current for you.

The photo below shows 2 pushbuttons connected to 2 GPIO pins: Port 9 Pins 12 (purple wire) and 15 (green wire).

Pin 12 is configured with a pull-up resistor by default.  (Note that there is a typo in the System Reference Manual: the pin name is gpmc_ben1, not gpmc_be1n. )

root:/sys/kernel/debug/omap_mux# cat gpmc_ben1
 name: gpmc_ben1.gpio1_28 (0x44e10878/0x878 = 0x0037), b NA, t NA
 mode: OMAP_PIN_OUTPUT | OMAP_MUX_MODE7
 signals: gpmc_ben1 | mii2_col | NA | mmc2_dat3 | NA | NA | mcasp0_aclkr | gpio1_28

So, the circuit for connecting a button is quite simple:

• Pin 12 to Button (purple wire)
• Button to Ground

When the button is pressed, the value will change from 1 to 0, making the button behave like a normally closed button (unless you actually have a normally closed button – hey, so that’s what those crazy NC buttons are for!). Be sure to account for this in your code.

root:/sys/class/gpio# echo 60 > export
root:/sys/class/gpio# cd gpio60
root:/sys/class/gpio/gpio60# cat value
0

Pin 15 is, by default, configured to use pull-down resistors.

root:/sys/kernel/debug/omap_mux# cat gpmc_a0
name: gpmc_a0.gpio1_16 (0x44e10840/0x840 = 0x0027), b NA, t NA
mode: OMAP_PIN_OUTPUT | OMAP_MUX_MODE7
signals: gpmc_a0 | mii2_txen | rgmii2_tctl | rmii2_txen | NA | NA | NA | gpio1_16

You can, of course, change that mux setting if you want to use the same simple button circuit as with Pin 12, but for the sake of variety I’ve hooked it up as-is:

• Pin 15 to button
• Button to 1K resistor
• Resistor to 3.3V

The resistor value is actually quite unimportant, as long as it’s 550R or higher.  While the Beaglebone’s GPIO pins don’t like high current, they have no problem with very low current, so 1K, 10K or 100K resistors should all work.

With the button connected to Pin 15 held down, we get a value of 1:

root:/sys/class/gpio# echo 48 > export
root:/sys/class/gpio# cd gpio48
root:/sys/class/gpio/gpio48# cat value
1

As promised, I’ll be showing some code that reads the buttons using some cutting edge polling technology, but first let’s take a look at PWM.

Enabling PWM Support in the Kernel

PWM support was added to version 3.2 of the Angstrom kernel.  (I believe it was initially in 3.2.0, but I didn’t start working with it until 3.2.6.)  These kernel updates were delivered via opkg updates in February.

Unfortunately, while opkg delivers the new kernels, it doesn’t activate them.  That requires some manual intervention.  Let me walk you through it…

First, check what kernel version you are currently running

root:~# uname -r
3.2.6+

If you have 3.2.6+ (or later), then great, you’re ready to go.  Skip ahead to the Activating the PWM Clock section below.

Otherwise, you’ll need to update the kernel.

[Update Sept 11: I just switched to the latest Angstrom image (stamped 2012.08.14) from the demo files page, and found -- to my shock and awe -- that the process of upgrading the kernel is a lot simpler.  Just, update the packages and reboot:

okg update

opkg upgrade

shutdown -r now

This brought me from kernel version 3.2.25 to 3.2.28.  Groovy!

This is news to me, so I don't know whether you're likely to have the same experience in other Angstrom images. If you don't get the kernel automagically installed through this method, then read on...]

Check to see what kernels have been installed by opkg:

root:~/tmp# ls -l /boot
total 12180
-rwxr-xr-x 1 root root      33 Feb 14 18:31 uEnv.txt
lrwxrwxrwx 1 root root      13 Mar  7 20:26 uImage -> uImage-3.2.9+
-rw-r--r-- 1 root root 3042328 Jan 26 12:49 uImage-3.1.0+
-rw-r--r-- 1 root root 3135840 Feb 10 03:57 uImage-3.2.0+
-rw-r--r-- 1 root root 3137472 Feb 22 05:37 uImage-3.2.6+
-rw-r--r-- 1 root root 3140088 Mar  6 13:47 uImage-3.2.9+

Right now (mid March), the latest and greatest is 3.2.9+.

If you don’t have the 3.2.x kernels listed in /lib/modules, then be sure to update your packages:

opkg update
opkg upgrade

If the opkg fairy still didn’t leave a new kernel under your pillow, then you might need to upgrade to a new image on the SD card.

Currently, the latest image is the February 14^th “2012.02” version, which shipped with Revision 5 of the Beaglebone.  You can download it from the Beaglebone Demo page  or from CircuitCo .  Circuitco’s page has instructions for installing the image to an SD card using Windows.  This image comes with the 3.2.5+ kernel, which supports PWM, but after giving it a spin you’ll probably want to go ahead and upgrade to the latest kernel anyway.

When opkg delivers the kernels, it doesn’t install them.   To start using a new kernel, you need to manually install it onto the boot partition of the SD card – you can easily do this right from the Beaglebone command prompt.

Begin by mounting the boot partition.  You need to use a directory as a mount point: I’m using one called tmp:

root:~# mkdir tmp
root:~# mount /dev/mmcblk0p1 tmp

If you look at the mount point, you should see the following files:

root:~# ls tmp
Docs     LICENSE.txt  README.htm    u-boot.img  uImage
Drivers  MLO          autorun.inf  info.txt    uEnv.txt

Overwrite the uImage with the latest kernel file from /boot:

root:~# cp /boot/uImage-3.2.9+ tmp/uImage

Unmount to make sure everything is nicely tucked away on the SD card, then reboot:

root:~# umount tmp
root:~# shutdown -r now

After rebooting, your system should report the new kernel:

root:~# uname -r
3.2.9+

Activating the PWM Clock

Update Dec 16 2012 – As pointed out in the comments, the PWM clock is activated by default in the current Angstrom version, Revision A6A.  If you are running an up-to-date Angstrom image, you can skip this section.

By default, the 3.2 kernel supports PWM, but doesn’t enable it.  If you try to use it through the file system, you’ll get “segmentation errors” and a lot of other moaning and groaning from the kernel.

As explained in this post on the Beagleboard group, the PWM clock needs to be enabled before you start using PWM.

The clock control register is documented in the AM335x Technical Reference Manual as follows:

The clock register isn’t exposed through the file system, so the only way to change this setting is by directly updating the register in memory.  Fortunately another post in the Beagleboard group provided the necessary code:

I’ve put a copy of the code here.  To run it on the Beaglebone:

root:~# opkg install python-mmap
root:~# wget http://www.gigamegablog.com/docs/setPWMReg.py
root:~# python setPWMReg.py

You should see:

Register CM_PER_EPWMSS1_CLKCTRL was 0x30000
Register CM_PER_EPWMSS1_CLKCTRL changed to 0x2

So, the IDLEST field is initially set to Disable – the code clears that field, and set the MODULEMODE field to ENABLE.

Having got the clock up and running, we’re ready to control the PWM settings through the file system.

Controlling PWM Using the File System

There are 2 pins on Port 9 that, by default, are configured for PWM, Pins 14 and 16.  The Beaglebone System Reference manual identifies these as EHRPWM1A and EHRPWM1B; to the file system, they are ehrpwm.1:0 and ehrpwm.1:1, respectively.

The “EHR” part means Enhanced High Resolution.  There is also a second type of PWM pin on the Beaglebone, called ECAP, or Enhanced Capture.  The 2 types of PWM pins have similar settings exposed through the file system, as explained in the AM335x PWM Driver’s Guide on the TI web site.

To me, the most important difference between the 2 type of PWM is that I can’t get ECAP to work.  So, let’s give the EHR PWM a whirl.

A good way to experiment with the PWM settings is to connect the positive pin of an LED to one of these pins, and negative pin of LED to ground.  You can safely do so without using a resistor, assuming the LED can be powered by the 3.3V that comes out of these pins.

A garden variety red or white LED should be fine – in the photo below, I have a red LED connected to pin 14.

[Updated Apr 25: Added the mux mode settings]

For starters, set the mux mode settings for the 2 pins to Mode 6 for EHRPWM:

root:~# echo 6 > /sys/kernel/debug/omap_mux/gpmc_a2
root:~# echo 6 > /sys/kernel/debug/omap_mux/gpmc_a3

There are a variety of PWM settings exposed through the file system, as described in the PWM Driver’s Guide, but the two key ones are period_freq, which is the frequency in Hz, and duty_percent, the duty cycle setting.

The following will blink the LED slowly, once per second: [Updated Mar 25: Before changing the period_freq  setting, duty_percent should be set to 0.  Otherwise, the value of duty_percent might be (silently and mysteriously) reset to another value]

root:~# cd /sys/class/pwm/ehrpwm.1:0
root:/sys/class/pwm/ehrpwm.1:0# echo 0 > duty_percent
root:/sys/class/pwm/ehrpwm.1:0# echo 1 > period_freq
root:/sys/class/pwm/ehrpwm.1:0# echo 50 > duty_percent
root:/sys/class/pwm/ehrpwm.1:0# echo 1 > run

The following settings will cause the LED to glow dimly [Corrected Mar 20]

root:/sys/class/pwm/ehrpwm.1:0# echo 0 > run
root:/sys/class/pwm/ehrpwm.1:0# echo 0 > duty_percent
root:/sys/class/pwm/ehrpwm.1:0# echo 200 > period_freq
root:/sys/class/pwm/ehrpwm.1:0# echo 20 > duty_percent
root:/sys/class/pwm/ehrpwm.1:0# echo 1 > run

To make the LED glow more brightly:

root:/sys/class/pwm/ehrpwm.1:0# echo 80 > duty_percent

It’s safe to change the duty_percent setting on the fly, without changing the other settings first.

The TI guide advises checking the availability of the PWM pin first:

root~:/sys/class/pwm/ehrpwm.1:0# cat request
 ehrpwm.1:0 is free

I haven’t seen it return anything except “free” yet, so I’m not sure under which circumstances it returns “busy”.  But, feel “free” to check.

With the second PWM port, right next door,  I decided to try a high-power LED with this one, the CREE XLAMP. This is actually a good use of PWM, since without it the CREE’s brightness makes it a pain to work with.  (I blinded me with science!)

Here, the GPIO pin’s current restriction is a problem: the CREE won’t even flicker with the max recommended output current of 6mA.  The 300 mA that flows out of the 3.3V port will do the trick, though.

To control the flow using PWM, you can use a transistor.  I used a common NPN “switching” transistor, the 2N2222.

The base of the transistor can be connected to the PWM pin, through a resistor. The resistor keeps the current within the recommended 4-6 mA for a GPIO pin.  I used a 1K resistor, but as with the digital input sensors the exact value doesn’t matter as long as you’re above 550R:  you don’t need much current to control the transistor base.

• Pin 16 to 1K resistor.
• Resistor to Base
•  3.3V to positive pad of XLAMP
• Negative pad of XLAMP to Collector of 2N2222
• Emitter of 2N2222 to ground

With this circuit, and a duty cycle of just 1%, the XLAMP is no longer blinding (though still surprisingly bright).

A couple of things to note about the frequency setting:

• Corrected Mar 21: As pointed out by muhoo in the Comments section, you can take the PWM frequency well past 250 Hz.  The key is to set the duty_cycle to zero before changing the frequency.  I’m not sure what the actual maximum frequency is, but the file system allows it to be set to 10 Mhz:

# echo 0 > run
# echo 0 > duty_percent
# echo 10000000 > period_freq
# echo 50 > duty_percent
# echo 1 > run
# cat period_freq
10000000
# cat period_ns
100

• The maximum is 250 Hz.  I actually couldn’t find this documented anywhere, but currently setting it to anything above that value returns an error message.  (There is an alternative setting of period_ns, but the minimum for that is 4 million – same difference.)

root:/sys/class/pwm/ehrpwm.1:0# echo 251 > period_freq sh: echo: write error: Invalid argument

• The frequency setting is shared between ehrpwm.1:0 and ehrpwm.1:1 — if you change it for one, the other will be automatically set to the same frequency.  So, unlike the duty_percent, you’ll probably want to set the “run” flag to 0 for both PWM devices before changing it.

Programmer’s Show And Tell

There aren’t many interesting ways to combine digital input and PWM output, and I’ve set out to prove this with some sample Python code  I’ve used one of the buttons and the 2 PWM-driver LEDs from earlier in the article.  Press the button and the lights come on.  Press and hold the button, and light state toggles between on and off.  Whee!

You can download the program from my Google Code site.

There are, however, a few things worth pointing out in the code.

Firstly, I’ve (ahem) borrowed the pin mode table from bonescript in order to implement Python versions of pinMode, digitalRead and digitalWrite .

Python’s Dictionary is an easy-going data type: you can store anything in it, including another dictionary.  This  is similar to node.js, so the syntax of the bone_pins definition is almost identical to its bonescript counterpart:

bone_pins = { "P8_1": { "name": "DGND" },
 "P8_2": { "name": "DGND" },
 "P8_3": { "name": "GPIO1_6", "gpio": gpio1+6, "mux": "gpmc_ad6", "eeprom": 26 },
 "8_4" : . . .

Adding more information to a pin definition is just a matter of adding another entry to the dictionary.  So, to extend the table to include PWM pins, I just added a “pwm” key …

"P9_14": { "name": "EHRPWM1A", "gpio": gpio1+18, "mux": "gpmc_a2", "eeprom": 34, "pwm" : "ehrpwm.1:0" },
 "P9_16": { "name": "EHRPWM1B", "gpio": gpio1+19, "mux": "gpmc_a3", "eeprom": 35, "pwm" : "ehrpwm.1:1" },

To check if a pin supports pwm:

if not "pwm" in bone_pins[pin]:
   print "ERROR: pin %s does not support PWM" %  pin

Like node.js, Python provides a command line for experimenting with code without running the full application. So, you can take advantage of these functions by loading the module, then calling the functions manually.

This is somewhat quicker and a lot easier than controlling the settings from the Linux command prompt.  For example, to set Port 8 Pin 5 for input, then check the current input value (you’ll need to run python from the directory that contains ButtonsAndLights.py):

root:~# python
>>> import ButtonsAndLights as bb
>>> bb.pinMode("P8_5", "in")
 setting /sys/kernel/debug/omap_mux/gpmc_ad2 to 0x37
 getting direction /sys/class/gpio/gpio34/direction
 exporting GPIO 34
 Exported /sys/class/gpio/gpio34/direction is in

 >>> bb.digitalRead("P8_5")
 /sys/class/gpio/gpio34/value is 1
 1

The extra “verbiage” are some print statements in the Python code for debugging purposes – I haven’t fully cleaned up the code yet to make it more usable as a plug-in module. For a more polished and better performing Python implementation of digital I/O functions, take a look at PyBBIO.  This code interacts with the GPIO pins using direct register access, rather than the file system, so PyBBIO should prove much faster, perhaps fast enough to handle the microsecond-level timing needed to implement device drivers.

I’ve also implemented pwmMode, pwmStart and pwmStop functions.  (This time I didn’t go with the Arduino naming convention – I can’t bring myself to refer to PWM as “analogWrite” like those bohemian Arduinoists.).

def pwmWrite(pin, frequency, duty_cycle, start = True):
 """ Changes settings of specified PWM pin (e.g. "P9_14") and optionally enables it.
 Note that frequency and duty_cycle can be omitted to leave them unchanged """

def pwmStart(pin):
 """ Turn on PWM on the specified pin. PWM settings must previously have been passed to pwmWrite() """

def pwmStop(pin):
 """ Turn off PWM on the specified pin """

These, too, can be used from the Python command line.  To set Port 9 Pin 14 to run at 200 Hz 80%:

>>> bb.pinMode("P9_14", "pwm")
 setting /sys/kernel/debug/omap_mux/gpmc_a2 to 0x6
>>> bb.pwmWrite("P9_14", 200, 80)
>>> bb.pwmStart("P9_14")

Last, and least, there is the polling for digital input:

lastButtonState = digitalRead(BUTTON_NC_PIN)
while 1 == 1:
    buttonState = digitalRead(BUTTON_NC_PIN)

    # NOTE: will return another value if unable to read
    if buttonState == HIGH or buttonState == LOW:
         if buttonState != lastButtonState:
         # do stuff
    time.sleep(BUTTON_POLL_INTERVAL / 1000.0)

While polling is, um, rather quaint, the AM335x is fast enough that it doesn’t significantly slow things down – the polling done in the sample code, once every 250 ms, spends about 99% of its time sleeping.

However, polling becomes somewhat less quaint when you’ve got a lot of digital inputs or sensors to keep track of, so I’m still looking for an interrupt driven solution for GPIO pins.  If anyone has that working from Python on a Beaglebone, please let me know.

Wrapping Up

These are still early days for the Beaglebone, and some of the basic building blocks for hobbyists are yet to fall in place.  No big surprise, of course: when the Arduino first appeared (back in the day, naught-5 I believe it was) it lacked libraries for things like LCDs and I2C sensors, but over the next few years those were written and became standardized.

But I’ve noticed quite a few interesting projects over the last month pushing out the boundaries of what can be done with userspace applications, like the aforementioned PyBBIO project,  and this bonescript project that writes to a Nokia 5110 display.

The kernel continues to leap ahead with new releases every few weeks: kernel maven Koen Kooi recently posted a proposed roadmap for what lies ahead.

The Beaglebone has also popping up on some popular hobbyist sites, like Make Magazine and Hack-A-Day.

It’s quite fun to watch a platform grow from the ground up!
